Magazine Buffer
Magazine Buffer is used as multi-function machine, work as a mid-line loader or unloader, as a LIFO and FIFO buffer.
Includes
> Omron PLC
> 3-Color Light Tower Display for Machine Status
> 7” HIMI Touchscreen Interface
> Width Adjustment By Hand Crank
> 4.8mm ESD Flat Belt
> Panasonic Sensors CX-422
> 2 Meters Long SMEMA Cable
Models
Model
PCB Length
PCB Width
Rack Dimension
MB250
50-350 mm
50-250 mm
355 x 320 x 563 mm
MB330
50-460 mm
50-330 mm
460 x 400 x 563 mm
MB390
50-535 mm
50-390 mm
535 x 460 x 570 mm
MB460
50-535 mm
50-460 mm
535 x 530 x 570 mm
> Selectable FIFO, LIFO, loader, unloader and reject stock mode
> Pass-through Function
> 1 magazine loading capability, discharge magazine from the rear of machine
> 50 pcs PCBs storing capacity
> Selectable pitch settings
> Variable speed control
> SMEMA compatible
> CE certified
|
Description |
Magazine Buffer 250mm,330mm, 390mm, 460mm | |||
|
Model No |
MB250 | MB330 | MB390 | MB460 |
|
Max PCB Size (LxW) |
350×250 mm | 460×330 mm | 535×390 mm |
535×460 mm |
|
Magazine Size(LxWxH) |
355x320x563 mm | 460x400x563 mm | 535x460x570 mm | 535x530x570 mm |
|
Max PCBs Capacity: |
50 pcs | |||
|
Loaded Weight |
Max 50 kilos each magazine | |||
|
PCB Loading Time |
± 7 seconds | |||
|
Magazine Change-Over |
± 25 seconds | |||
|
Power Supply |
AC220 ±10v, 50 Hz /110V ±10v, 60 Hz | |||
|
Air Supply |
5~6 kg/cm² (4~6 bar) | |||
|
Conveyor Height |
890-950mm | |||
|
Flow Direction |
Left to right |
|||
| Fixed Rail |
Front |
|||
| Component Clearance |
Bottom 25 mm |
|||
| Pitch |
10mm, 20mm, 30mm, 40mm |
|||
| Machine Dimension(LxWxH) | 1230x1290x1200 mm | 1350x1450x1250 mm | 1450x1570x1250 mm |
1450x1710x1250 mm |
| Net Weight | 220 kgs | 245 kgs | 260 kgs |
280 kgs |
| Shipping Dimension(LxWxH) | 1380x1340x1450 mm | 1500x1600x1450 mm | 1600x1720x1450 mm |
1600x1860x1450 mm |
|
Gross Weight |
296 kgs | 335 kgs | 359 kgs |
384 kgs |
Safety Cover
Change from ESD Flat Belt to Pin Chain Conveyor
Line Central Auto Width Adjustment-Follow Me System
Right to Left Flow
Other Options Available on Request
Use quality parts to assemble the machine based on many years of experience to ensure complete stability of machines, which is essential to make sure fewer service calls, fewer down time.
